The Rapid+ 5000/48V is a 4750VA / 3800W pure sine wave inverter that Invertek grades for factories and offices. It runs on a 48V battery bank and has a 24×7 MCB and a DC MCB.
Original price was: ₹41,990.00.₹31,104.00Current price is: ₹31,104.00.
The Rapid+ 5000/48V is a 4750VA / 3800W pure sine wave inverter that Invertek grades for factories and offices. It runs on a 48V battery bank (four 12V batteries in series) and has a 24x7 double-pole DC MCB on the battery side.
"5000" is the model number, not the VA rating. This model has a 24-month warranty, not the 36 months on the 12V and 24V models, and 48V systems are best installed by an electrician who can size the battery bank and cables.
The 3,800 W figure is a resistive (bulb load) rating. Motors such as fridge compressors and pumps draw a short surge when they start, so count them a little heavier. Typical draws are below; check the label on your own appliances.
| Appliance | Typical running draw |
|---|---|
| Ceiling fan | 60–80 W (BLDC fan: 30–35 W) |
| LED bulb or tube | 9–20 W |
| Desktop PC with monitor | 150–300 W |
| CCTV cameras with recorder | 30–80 W |
| Double-door frost-free refrigerator | 150–300 W, plus a start-up surge |
| Water pump (0.5 HP) | 400–600 W, with a higher start-up surge |
| 1-ton inverter AC | 700–1,000 W once running, more at start-up |
| 1.5-ton inverter AC | 1,000–1,400 W once running, more at start-up |
A working example: a 1-ton inverter AC (900 W), eight fans (560 W), twenty LED lights (200 W), four desktop PCs (1,000 W) and CCTV and network gear (110 W) come to roughly 2,770 W, about 73% of the 3,800 W rating. As a rule of thumb, keep the continuous load below about 3,040 W, which is 80% of the rating.
Heating appliances such as geysers, room heaters, induction cooktops and irons are within the rating on paper, but they empty a lead-acid battery bank in minutes. Leave them off during a power cut.
The Rapid+ 5000/48V is a 48V system, so it needs a 48V battery bank: four 12V batteries connected in series, or a 48V lithium battery. Connecting batteries in series raises the voltage, not the capacity: four 12V 200Ah batteries make a 48V 200Ah bank. The inverter is sold without batteries.
To estimate backup time, multiply battery volts by amp-hours, take about half of that as usable for a lead-acid battery, multiply by 0.85 for inverter losses, and divide by your load in watts. For four 12V 200Ah tubular batteries in series (9,600 Wh) that works out to about 1.5 hours at 2,770 W and about 2.7 hours at 1,500 W. A 51.2V 100Ah LiFePO4 battery (assuming 90% usable) gives about 1.4 hours at 2,770 W. These are calculations with an assumed 85% inverter efficiency, not lab measurements; heavy loads, battery age and temperature all shorten real backup.
| Model | Rated capacity | Battery voltage | Display | Suits |
|---|---|---|---|---|
| Rapid+ 4000/24V (3500VA) | 3500VA / 2800W | 24V | LCD | 4BHK or office with a 1.5-ton AC |
| Rapid+ 5000/48V (this model) | 4750VA / 3800W | 48V | LCD | Factory and office grade (48V) |
| Rapid+ 5500/48V (5250VA) | 5250VA / 4200W | 48V | LCD | Industrial grade (48V) |
| Rapid+ 7500/48V (6500VA) | 6500VA / 5200W | 48V | LCD | Flagship commercial (48V) |
The inverter carries a 2-year (24-month) warranty. Register it on the warranty registration page after installation. Shipping is free on all orders, with standard delivery in 5–7 days. If you are unsure about sizing, call 9311369797 before you order. Invertek Energy makes its UPS range at its ISO 9001:2015 certified factory in New Delhi. Other capacities are listed in the full other Rapid+ sizes.
| Model Series | Rapid+ 5000/48V |
|---|---|
| VA Rating | 4750VA/48V |
| Product Dimensions | 390X277X345 mm |
| Package Dimensions OD Size (mm) | 370x470x425 mm |
| Item Part Number | IE-SNW-INHUPS-4500-02A |
| Number of Items | 6 |
| Wattage | 3800W |
| Power Source | Inverter/ Home UPS |
| Frequencies | 50Hz |
| Manufacturer | Invertek Energy |
| Generic Name | Inverter/UPS |
| Included Components | 1 Inverter, Operating Manual, 3 Battery jointer, Silica gel |
| Item Weight | 29.5 kg |
| Package Weight | 30.5 kg |
| Country of Origin | India |
| HSN Code | 8504 |
Q: Is 5000 the VA rating of the Rapid+ 5000/48V?
No. 5000 is the model number. The Rapid+ 5000/48V is rated 4750VA / 3,800 W on a 48V battery system. When you compare it with other inverters, compare the VA, watt and battery voltage figures rather than the model number.
Q: What can the Rapid+ 5000/48V run?
It suits a factory, an office or a large commercial space. For example, a 1-ton inverter AC (900 W), eight fans (560 W), twenty LED lights (200 W), four desktop PCs (1,000 W) and CCTV and network gear (110 W) come to roughly 2,770 W, about 73% of the 3,800 W rating. Keep the continuous load under about 3,040 W.
Q: What kind of site does the Rapid+ 5000/48V suit?
Invertek grades it for factories and offices. It can carry several PCs, fans, lights, CCTV and an AC within 3,800 W, for example 2,770 W in our worked example. A 48V bank of four batteries should be sized and wired by an electrician.
Q: How many batteries does the Rapid+ 5000/48V need?
Four 12V batteries connected in series to make a 48V bank, or a single 48V lithium battery. Series connection raises the voltage, not the capacity: four 12V 200Ah batteries give a 48V 200Ah bank. The inverter is sold without batteries, so have the bank sized for your load and backup time.
Q: How long will the backup last?
Backup time is usable battery watt-hours divided by your load. With four 12V 200Ah tubular batteries in series, using about half of the battery capacity and assuming 85% inverter efficiency, expect about 1.5 hours at 2,770 W and about 2.7 hours at 1,500 W. Switching off unused loads extends this. These are estimates, not measured results.
Q: Can I use a lithium battery with the Rapid+ 5000/48V?
Yes. It is lithium compatible, so you can fit a 51.2V LiFePO4 battery now or swap one in later. At full load the inverter draws roughly 80 to 95 A from the battery, so choose a battery whose BMS is rated for at least that current.
Q: How is it different from the Rapid+ 4000/24V and Rapid+ 5500/48V?
The Rapid+ 4000/24V is rated 3500VA / 2,800 W on 24V. This model is 4750VA / 3,800 W on 48V. The Rapid+ 5500/48V is 5250VA / 4,200 W on 48V and suits an industrial or commercial site.
Q: What happens if I overload the Rapid+ 5000/48V?
The 24x7 MCB trips when the load goes past the 3,800 W rating or the output is shorted. Switch off the heaviest appliances and switch the MCB back on; nothing needs replacing. Keep the continuous load under about 3,040 W to avoid nuisance trips. The double-pole DC MCB protects the battery side.
Q: What warranty does it have?
2 years (24 months). Register the unit on the warranty registration page after installation. For service, call 9311369797.
Bought the Rapid+ 5000/48V for our home in our village near Hisar because of voltage fluctuations. It easily backs up fridge, fans and a few LED lights and the sine wave output is very smooth, no humming sound from the fans or fridge. Installation by the local electrician was quick and simple. Overall really satisfied with the purchase, would recommend to anyone facing voltage fluctuations. Haven't needed service yet but the warranty gives peace of mind.
Bought the Rapid+ 5000/48V for our home in Rajkot because of voltage fluctuations. It easily backs up AC in one room along with fans and lights and the sine wave output is very smooth, no humming sound from the fans or fridge. The technician who installed it explained everything clearly. Overall really satisfied with the purchase, would recommend to anyone facing voltage fluctuations. Haven't needed service yet but the warranty gives peace of mind.
Bought the Rapid+ 5000/48V for our home in Bhubaneswar because of voltage fluctuations. It easily backs up fridge, fans and a few LED lights and the sine wave output is very smooth, no humming sound from the fans or fridge. Our electrician said the wiring and build quality are solid. Overall very happy with the purchase, would recommend to anyone facing voltage fluctuations. The dealer explained the warranty terms clearly at the time of purchase.
Bought the Rapid+ 5000/48V for our home in Bhopal because of unscheduled outages during monsoon. It easily backs up washing machine, fridge and fans and the sine wave output is very smooth, no humming sound from the fans or fridge. Installed it myself in about half an hour, quite easy. Overall really satisfied with the purchase, would recommend to anyone facing unscheduled outages during monsoon. Haven't needed service yet but the warranty gives peace of mind.
Bought the Rapid+ 5000/48V for our home in Madurai because of voltage fluctuations. It easily backs up lights, fans and my son's online classes setup and the sine wave output is very smooth, no humming sound from the fans or fridge. Installation by the local electrician was quick and simple. Overall really satisfied with the purchase, would recommend to anyone facing voltage fluctuations. Support team responded quickly when I had a doubt about the battery.
